Gen. Purpose Relay Contactor 4 poles - NO -110/120 VAC - 4DS-A12060 - Replaces DPBF09 T4 A12060 https://4ds-t-d-inc.myshopify.com

Relay Contactor 4 poles (NO) 110/120 VAC - 4DS-A12060 - Replaces DPBF09 T4 A12060

4D's T&D Inc

Regular price $35.53 Sale

General Purpose Motor Contactor / Relay - 4 poles, 4 NO contacts

Replaces Part # - DPBF09 T4 A12060.

Our Part # 4DS-A12060.   Price $35.53 ea.

Features:

  • Number of Poles: 4
  • Number of contacts: 4 NO
  • Single phase load: (a) 120 Vac/1.5 hp (b) 240 Vac/3.0 hp (c)  208 Vac/ 5.0 hp (d) FLA 20 Amps.
  • Three phase load: (a) 240 Vac/ 5.0 hp (b) 480 Vac /10.0 hp (c) 600 Vac/15.0 hp.
  • Coil voltage: 110/120 VAC/ 50 - 60 Hz.
  • Dimensions: Dp 3.2" (82 mm) x W 1.8" (45 mm) x H 3.2" (82 mm).
  • DIN-Rail mountable

Ideal for motor starters, air conditioning, heating, refrigeration, ventilation, etc.
